product description

1, Features: The product is artificial graphite, long cycle life, excellent processing performance, cost-effective, stable and reliable performance.

2, the scope of application: high-energy density cylindrical, square aluminum and other lithium-ion battery.

Use reference suggestions

1, the material design specific capacity of 335 ~ 345mAh / g over 5 ~ 8%, compaction density design ceiling of 1.55g / cm3 or so (according to the surface density and battery type appropriate adjustment);

Physical and chemical indicators

Reference formula and design

Slurry Reference Formulation: ZT-ES1: CMC: SBR: SP = 94.5: 2.0: 2.5: 1.0

Slurry viscosity: 1500 ~ 3500

Slurry solid content: 40 ~ 55%

Reference Electrolyte: 1.0M-LiPF6 EC / DMC / EMC + Additive; 1.0M-LiPF6 EC / DEC + Additive
