product description

1, Features: The product is high-end artificial graphite anode material, with high grams of capacity, high pressure density, low expansion, good cycle performance, better rate performance, high and low temperature performance and excellent safety performance characteristics.

2, the scope of application: high capacity, long cycle power (3C below charge and discharge) lithium battery.

Use reference suggestions

1, the material design capacity of 350mAh / g over 5 ~ 8%, compaction density design limit of about 1.60g / cm3 (according to the surface density and the appropriate type of battery adjustment);

Physical and chemical indicators

Reference formula and design

Slurry Reference Formulation: ZT-H7-2: CMC: SBR: SP = 95.0: 1.8: 2.2: 1.0

Slurry viscosity: 2000 ~ 4500mPas

Slurry solid content: 40 ~ 55%

Reference Electrolyte: 1.0M-LiPF6 EC / DEC (DMC) /EMC+Additive; 1.0M-LiPF6 EC / DEC + Additive
